Two position five way solenoid valve is an automatic basic element used to control fluid, belonging to actuator; Not limited to hydraulic and pneumatic. The solenoid valve is used to control the hydraulic flow direction. The mechanical devices in the factory are generally controlled by the hydraulic cylinder, so the solenoid valve will be used. The working principle of the solenoid valve. There is a closed chamber in the solenoid valve. There are through holes in different positions. Each hole leads to a different oil pipe. There is a valve in the middle of the chamber and two electromagnets on both sides. The valve body will be attracted to which side when the magnet coil is energized.
Different oil drain holes will be blocked or leaked by controlling the movement of the valve body. The oil inlet hole is normally open, and the hydraulic oil will enter different oil drain pipes, Then the oil pressure pushes the piston of the oil cylinder. The piston drives the piston rod, which drives the mechanical device to move. In this way, the mechanical movement is controlled by controlling the current of the electromagnet.
Usage Field : Yuchai, Cummins,Changchai engine, like Young man,Yutong , Higer , Golden Dragon , man, Heavy truck(Sino-truck, Dongfeng, Shacman , Foton ......) .
Usage : When the pneumatic system becomes more complex, greater adaptability of the pneumatic valve is required, and this valve provides this flexibility. This valve is called "five port four-way valve" in the field of fluid power. The valve uses a common inlet pressure source and two exhaust ports, which allows the exhaust to be controlled separately from each outlet of the valve.
Features
CHACS valve Advantages
Popular Brand
High Quality
Low Loss
Multiple Usage
Parameter
CHACS valve Parameter
Net Weight :
0.8kg
Gross Weight :
1.5kg
Packing Size :
20*15*15cm
Delivery Time :
3 business days
Shipping Term :
UPS,DHL,FRDEX,EMS
About Shipping fee :
Shipping fee not including any import tax, import tax paid by buyer .
Notes: "1. If you are satisfied with our products, please give us 5 stars.
2. If you are not satisfied with our products, please communicate with our customer service in time, we will try our best to solve the problem for you.
3. Your feedback is very important to us, please take a few minutes to give us an evaluation after receiving the goods, thank you very much!
4. We adhere to the highest standards and strive for 100% customer satisfaction."
